ISW horizontal centrifugal pump

ISW horizontal centrifugal pump is designed according to the unique structural combination of is centrifugal pump and vertical pump, and designed and manufactured in strict accordance with international standard ISO2858 and the latest national pipeline centrifugal pump standard JB / t53058-93. The pump is optimized by domestic advanced hydraulic model. At the same time, according to the different temperature and medium, hot water pump, high temperature pump, chemical pump and oil pump are derived from ISW type, which are the current national standard finalized and promoted products.

021-62586878

Product overview

ISW horizontal centrifugal pump is designed according to the unique structural combination of is centrifugal pump and vertical pump, and designed and manufactured in strict accordance with international standard ISO2858 and the latest national pipeline centrifugal pump standard JB / t53058-93. The pump is optimized by domestic advanced hydraulic model. At the same time, according to the different temperature and medium, hot water pump, high temperature pump, chemical pump and oil pump are derived from ISW type, which are the current national standard finalized and promoted products.

Model meaning:


Product features

Stable operation: absolute concentricity of pump shaft and excellent dynamic and static balance of impeller ensure smooth operation and no vibration.

No leakage: different materials of cemented carbide seal, to ensure that no leakage of different media transmission.

Low noise: two low-noise bearings under the pump, smooth operation, in addition to the motor weak sound, basically no noise.

Low failure rate: the structure is simple and reasonable, the key parts adopt the international first-class quality matching, and the trouble free working time of the whole machine is greatly improved.

Convenient maintenance: easy to replace seal and bearing.

Less land occupation: the exit can be left, right, up three directions, convenient for pipeline layout and installation, saving space.

Main uses

ISW type pipeline centrifugal pump is used for conveying clear water and other liquids with physical and chemical properties similar to clear water. It is suitable for industrial and urban water supply and drainage, high-rise building pressurized water supply, garden irrigation, fire-fighting pressurization and equipment matching. The operating temperature T: ≤ 80 ℃.

Iswr (WRG) hot water (high temperature) circulating pump is widely used in energy, metallurgy, chemical industry, textile, papermaking, hotels and restaurants, etc. boiler high temperature hot water pressurization circulation transportation and urban heating system circulation pump. Iswr operating temperature T: ≤ 120 ℃, WRG operating temperature T: ≤ 240 ℃.

Iswh type horizontal chemical pump is used to transport liquids without solid particles, corrosive and similar to water viscosity. It is suitable for petroleum, chemical, metallurgy, electric power, paper making, food, pharmaceutical and synthetic fiber departments. The operating temperature is t: - 20 ℃ - 120 ℃.

Iswb horizontal oil pump is used to transport gasoline, diesel oil, kerosene and other petroleum products. The operating temperature is t: - 20 ℃ - 120 ℃.

Service conditions:

Suction pressure ≤ 1.0MPa, or higher working pressure of pump system ≤ 1.6Mpa, i.e. pump suction pressure + pump head ≤ 1.6Mpa, pump static pressure test pressure is 2.5MPa, please indicate system working pressure when ordering. When the working pressure of pump system is greater than 1.6Mpa, it should be put forward separately when ordering. In order to make use of cast steel for the flow passage parts and connecting parts of the pump during manufacturing.

Ambient temperature < 40 ℃, relative humidity < 95%.

The volume content of solid particles in the conveying medium shall not exceed 0.1% of unit volume, and the particle size shall be less than 0.2mm

Note: if the medium used is with fine particles, please specify when ordering, so as to use wear-resistant mechanical seal.



Application scope of horizontal centrifugal pump:

1. ISW horizontal centrifugal pump is used for conveying clear water and other liquids with physical and chemical properties similar to clear water. It is suitable for industrial and urban water supply and drainage, high-rise building pressurized water supply, garden sprinkler irrigation, fire-fighting pressurization, long-distance transportation, heating and ventilation refrigeration cycle, bathroom and other cold and warm water cycle pressure increase and equipment matching, and the service temperature is less than or equal to 80 ℃.

2. Iswr horizontal hot water pump is widely used in metallurgy, chemical industry, textile, papermaking, guest tube, hotel and other boiler hot water circulation pressurization and urban heating system. ISW type service temperature T ≤ 120 ℃.

3. Iswh horizontal chemical pump is suitable for petroleum, chemical, metallurgy, electric power, papermaking, food, pharmaceutical and synthetic fiber sectors, with service temperature of - 20 ­ 120 ℃.

4. Iswb horizontal pipeline oil pump is used to transport oil, kerosene, diesel oil and other oil products or flammable and explosive liquids. The temperature of the medium to be transported is - 20-120 ℃.
